Input Characteristic
| Minimum | Nominal | Maximum | |
| Input Voltage | 90Vac | 100Vac~240Vac | 264Vac |
| Input Frequency | 47Hz | 60Hz/50Hz | 63Hz |
Output Characteristics
| Output | Rated Load | Output Range
|
R+N
|
Remark
|
|
| Rate | Min. Load | Max. Load | |||
| 12V/24v | 0.0A | 25A/10A | 3.3V ~15.5V/16V ~29.6V | 300mVp-p | |
Maximum output power:350W
Models of the clamp for now available （can be customized）：
· 61CM Patent Clamps（Standard length）/120CM Patent Clamps (With XT30 detachable plug、M6 connecting ring )
· 61CM Global clamps(standard length)
The length of the power cord can be selected：
· 70CM(standard length）/ 90CM/120CM/150CM/200CM
Details of the connecting port:
